WoodDesign _ SEED OF LIFE

Sophisticated design requirements and a high level of energy efficiency: timber and aluminium combined in a single block window system

With AWS WoodDesign, the design possibilities offered by the Schüco AWS 75 BS.SI+ (Block System Super Insulated) window system are expanded even further with a new material: timber. The room side of the Schüco WoodDesign vent profiles is clad with timber decorative strips, creating a window which combines the best of both worlds: the high performance characteristics and narrow profile face widths of an aluminium block window with a basic depth of 75 mm alongside the natural cosiness of a timber surface finish.

A selection of seven pre-defined oakwood surface finishes allows the windows to blend seamlessly with any interior colour scheme. Individual timber colours can also be requested in consultation with the metal fabricator. The design is rounded off with an attractive range of new and pre-existing handles. This allows for an enormous variety of design options, all while retaining the architectural advantages of a highly thermally insulated aluminium block window.

AWS 75 BS.SI+ WoodDesign is part of the Schüco AWS modular system, meaning the entire range of fittings and accessories is available to choose from. The functional, energy-saving and design properties of the window are also impressive, offering maximum transparency, narrow face widths and a concealed vent without visible glazing beads.

Description

Planning benefit

  • Seamless integration of design and function with aluminium outside and a timber surface finish inside
  • A wide range of design options for the timber decorative strips
  • A diverse range of handles in three designs
  • A block window system with a basic depth of 75 mm offering excellent thermal insulation, maximum transparency, narrow face widths and a concealed vent without visible glazing beads
  • Can be combined with concealed Schüco AvanTec SimplySmart system fittings to allow for large vent weights and sizes
  • Burglar resistance to RC1N/RC2N/RC2 in accordance with DIN EN 1627

Technical information

Specification Value
Min. face width 67 mm
Uf value of frame (≥) 1.4 W/(m²·K)
Max. glass/panel thickness 54 mm
Max. vent width 1500 mm
Max. vent height 2200 mm
Max. sound reduction index Rwp 49 dB(A)
Air permeability Class 4
Watertightness Class 9A
Burglar resistance Up to RC 2
Wind load resistance Class C5 / B5
CE marking Yes
Total basic depth 85 mm
Width of vent frame 85 mm
Max. vent weight 160 kg
Min.-max. vent height 540…2200 mm
Min.-max. vent width 470…1500 mm
Outer frame face width 67 mm
Max. face width of mullion 181 mm
Min.-max. face width of mullion 92…181 mm
Max. face width of meeting stile 83 mm
Min.-max. face width of meeting stile 83…83 mm
Min.-max. glass/panel thickness 16…54 mm
Area of application External use, Residential projects, Commercial projects, Healthcare, Education
Shear bond Yes
Concealed fittings system Yes
Surface finishes Powder, Anodise
