PANORAMA_ 100% SYSTEM SYNCHRONIZATION
ah!60 is a groundbreaking exterior opening system with unmatched thermal and acoustic performance (up to Minergie-P and Passivhaus), ideal for very cold climates. It also stands out as an intrusion prevention solution for high demanding security specifications (RC4). It offers great flexibility in the modular composition of openings, including opening corner solutions, pocket sliding configurations, curved layouts, tilted spans and retractable mosquito nets.
The alternatives come in a wide range of formats such as sliding and vertical sliding opening units. It allows for the introduction of a wide range of accessories, including heated glass, and it can be completely automated. ah!60 is a system that allows double glazed surface areas of up to 29m², or triple glazed of up to 19m². Both options use 20mm vertical profiles.
Technical Specifications
Technical Specification | Value |
---|---|
Thermal Coefficient (Uw) | 0.708 W/m²·K (entire window) |
Thermal Coefficient (Ug) | 0.41 W/m²·K (glazing only) |
Water Tightness | Class E900 |
Air Tightness | Class 4 |
Wind Resistance | Class C5 |
Sound Insulation | 44 dB |
Security | RC4 |
Certification | MINERGIE-P |
